ELUXEO™ 7000 Video Processor

The next generation of endoscopy systems: Fujifilm’s innovative 4-LED Multi Light™ technology supports advancing the standards of endoscopic imaging. Equipped with the new LCI (Linked Colour Imaging) and BLI (Blue Light Imaging) modes.

  • LCI differentiates the red colour spectrum more effectively than White Light Imaging thanks to its pre-process composition of light spectrum and advanced signal processing. The increased colour contrast in red colour leads to improved visibility of abnormalities, inflammation and delineation.
  • High-intensity contrast imaging with BLI is expected to be helpful for improved visualisation of superficial vascular and mucosal patterns. Focussing on the characteristics of short wavelength absorption of haemoglobin (at 410 nm) combined with specific white light spectral colours results in improved contrast imaging.
  • The novel function CAD EYE has been developed utilising AI deep learning technology and is compatible with Fujifilm’s ELUXEO™ endoscopy series to support endoscopic lesion detection and characterization in the colon.
Un produit de Fujifilm

Fujifilm ELUXEO™ 7000 optimising your daily work with our innovative solutions: Link for the  Endoscopes



More info about Multi LightTM, LCI, BLI:

BLIPortal Studies & Information



Description

VP-7000 HIGH PERFORMANCE VIDEO PROCESSOR

The ELUXEO™ video processor VP-7000 enables you to make use of the many features provided by Fujifilm’s wide range of endoscopes along with the 4-LED illumination system and its LCI and BLI visualisation modes.

In addition to the ELUXEO 700 series endoscopes, it is also compatible with the 600 and 500 series of endoscopes. The processor creates high-quality images displayed in full HD on the monitor. Automatic back-up mode for data storage is integrated and the processor is DICOM compatible.





BL-7000 4-LED MULTI LIGHT™ SOURCE WITH HIGH DURABILITY

A reliable light source is a prerequisite for use in large clinics as well as smaller outpatient centres to ensure procedures can take place as scheduled. To achieve high standards, the eco-friendly ELUXEO™ 7000 system features the 4-LED Multi Light™ Source, which outperforms conventional Xenon or Halogen light sources: With 10,000 hours average life expectancy for the LED lights, the ELUXEO™ system has far longer durability while having much lower energy consumption, resulting in better cost-efficiency.

Compatible scopes

700 / 600 / 500 series

Output

DVI-D x2, DVI-I x1, HD-SDI x2, RGB-TV x1, S VIDEO x1, VIDEO x1

Input

1 channel PoP

External memory

USB Flash Drive

Power rating

100 - 240V, 50 / 60Hz, 0.8 - 0.5A

Dimensions (w x h x d)

390 x 110 x 485 mm (including projection)

Weight

9.0 kg



Light source

4-LED

Air supply pump

High, Mid, Low, Off

Power rating

100 – 240V, 50 / 60Hz, 1.2 – 0.7A

Dimensions (w x h x d)

390 x 155 x 485 mm (including projection)

Weight

12.0 kg

Optical radiation safety

Class 1 LED product
